The body case and switch lever are made of anti-static resin to protect the components from static electricity.
[Surface resistance value: 104Ω or less]
Specifications:
| Start | Push to start type | |
| Output Torque Range | N.m | 0.1-0.55 |
| Ibf・in | 0.9-4.8 | |
| kgf・cm | 1-5.5 | |
| Torque Switching | Stepless Adjustment | |
| No-load rotation speed (rpm) ±10% | Low | 690 |
| High | 1000 | |
| Screw Size(mm) | Machine screw | 1.4-2.6 |
| Tapping screw | 1.4-2.3 | |
| Bit |
Hios shank (standard) | H4 |
| Hexagonal Shank | 1/4HEX or 5HEX | |
| Accessories |
Bits H4 | +#0(φ2.5×40mm) +#1(φ4.0×40mm) |
| Bits 1/4HEX | +♯0 (5.0×50mm) +♯2 (5.0×50mm) - (5.0×50mm) |
|
| Spring | Blue | |
| Driver cord length (m) | 1.5m(5p) | |
| Carbon brush order code | CL4-0420 (1 pair) | |
| Torque Range Table |  |
