With this, everyone is a skilled worker.
· By counting the number of rotation pulses of the motor, the screw tightening error is detected with higher accuracy in real time.
· Do not miss mixing of foreign screws or screw floating.
· Direct teaching makes setting easier.
· Display the screw tightening number on the display.
· System management with screw tightening error is possible with serial port.
Specifications:
| Start | Lever start type | |
| Output Torque Range | N.m | 0.1-0.55 |
| Ibf・in | 0.9-48 | |
| kgf・cm | 1-5.5 | |
| Torque Switching | Stepless Adjustment | |
| Unloaded Rotation Speed(r.p.m) | Low | 690 |
| High | 1000 | |
| Screw Size(mm) | Screw size | 1.4-2.6 |
| Tapping | 1.4-2.3 | |
| Bit | Hios shank | H4 |
| Hex shank | 1/4 Hex | |
| Power Supply | Model | BLC-45 BLC-70 BLC-80 |
| External Dimensions(mm) |
Grip | 32.7 |
| Length(m0) | 206 | |
| Weight(g) | 370 | |
| Accessories | Bit H4 | +♯0 (∅2.5×40mm) +♯1 (∅4.0×40mm) |
| Bit 1/4HEX | +♯1 (5.0×50mm) | |
| +♯2 (5.0×50mm) | ||
| -(5.0×50mm) | ||
| Spring | White | |
| Cord length(m) | 2m(6p) | |
| Torque Range Table |  |
